500, 1000, & 1600 Gallon Commercial Water Trailer Support
Videos
Guides
Getting Started notes
- The missing pump drain plug can be found inside the instruction tube.
- Check your oil before first use.
- Water Trailers shipped during cold months or to cold regions may be shipped with RV Antifreeze already run through the plumbing to prevent freeze damage.
Register Engine
The engine on the Compact Water Trailer is covered by an independent Honda warranty. Please register the engine by clicking on the button below.
Getting to Know Your Trailer
The gives an overview of ABI’s compact water trailer. While some features and plumbing setup differs, the basic concepts will assist you in your Commercial/DOT Trailer Operation as well.
Run 3-4 gallons of RV antifreeze in through entire system – all hoses, nozzles, and pumps. This will lubricate and prevent freezing and breakage. After circulating through pumps, open ratchet valve and once you see the pink spraying out the back, you will know that it has circulated and the entire system has been properly lubricated. Leave about 2 gallons of the RV Antifreeze in the tank to store for winter.
Cleaning
2 Gallons Bleach and 3 quarters full of tank full of water. Drive around and let it agitate around. Then let it soak for a few hours. Drive around again then drain and rinse.
